HX-009H Fully Automatic Tube Filling and Heat Sealing Machine

Advanced Features of the HX-009H Fully Automatic Tube Filling and Heat Sealing Machine

1. The mechanical transmission part is closed below the platform, which is safe, reliable and pollution-free;
2. The filling and sealing part is installed above the platform, and the semi-closed non-static outer frame is visible in the cover, which is easy to observe, operate and maintain;
3. Stainless steel operation panel, plexiglass protective cover and door protection function installed;
4. Slant-hanging tube warehouse, which can accommodate more tubes,
5. The upper tube device is equipped with a vacuum adsorption device. After the upper tube interacts with the pressure tube device, the tube is inserted into the upper tube station;
6. Photoelectric benchmarking station, using high-precision probes, stepping motors, etc. to control the tube pattern to be in the correct position;
7. No tube, no filling, when the injection is finished, the air blowing device blows off the paste tail; anti-drawing, anti-drip filling
8. The heating temperature of the end sealing adopts (Leister hot air gun) internal heating at the end of the tube, and the external cooling device is equipped;
9. At the same time of sealing the end, the production batch number or date is automatically embossed on the position required by the process;
10. Waste cutting manipulator cuts the waste edge at the tail of the tube, and seals with special shapes such as right angle, R angle or arc;
11. Failsafe alarm, overload shutdown, water pressure protection, air pressure protection.
